High Speed Melamine Auto Grinding Expert

Our Machine can Grinding all kinds of melamine dinnerware by automatic.
  • brand:

  • MOQ:

inquiry now
High Speed Melamine Auto  Grinding Expert

1:Deliver Material
Stacked placement  and manipulator auto-fetch the material to conveyer belt,Drastically reduce the personal operation time,the maximum quantity is 230pieces.
Melamine Auto Grinding Machine
2:Rough Grinding
1)   Can grind polygon products.
2)   Adjust the grinding speed and depth according to the burr thickness
3)   5seconds can grind one circle product as usual
4)   8seconds can grind one special shape product as usual
Melamine Auto Grinding Machine
3:Fine Grinding
1)   Flexible grinding,polishing surface after rough grinding.
2)   Reducing surface roughness,and round comers the acute angle after rough grinding.
3)   5seconds can grind one circle product as usual.
4)   8seconds can grind one special shape product as usual.
Crockery Auto Grinding Machine
1)   Buffing,for polishing surface after find grinding
2)   Automatically setting waxing time,auto alarm when no wax.
3)   5seconds can grind one circle product as usual

1)   Adjustable design,that the size and width can be adjusted according to products.
2)   Suitable for diameter 50mm-500mm
Dinnerware Auto Grinding Machine
Tableware Auto Grinding Machine
6:Receiving the materials
1)   After grinding,the manipulator collects the product and then stacking placement.
2)   The maximum collect quantity is about 230pcs

1: Problems encountered by melamine tableware manufacturers:
Difficulties in recruitment, seasonal orders, poor working conditions, high labor intensity, and difficult employee management.
2: automatic melamine tableware edging machine:
1) Machine points, coarse grinding, fine grinding, two grinding heads, automatic loading and unloading (receiving material, receiving material)

Tableware Auto Grinding Machine
2) Two grinding heads are finely ground and two grinding heads are ground. The grinding head can be automatically lifted and lowered, and the height is automatically controlled.
3: Machine and Labor Comparison:
1 machine = 1.5 workers (11 hours)
2 machines = 3 workers (11 hours)
3 machines = 4-5 workers (11 hours)
At present, the wages of edging workers are about RMB 4000-6000/month (skilled workers)
The automatic edging machine only needs an ordinary porter to discharge and receive materials. One person can operate at least 3 machines. The equivalent of an ordinary porter can replace 4-5 skilled edging workers (11 hours).
Machines can be produced 24 hours a day in two shifts. Two ordinary porters can replace 8-10 skilled edging workers.
The average porter is about RMB2500-3500/month, the two porters are paid RMB5000-7000/month, and the three machines can save about RMB27000-53,000/month each month.
4: Machine cost recovery: monthly labor cost savings RMB27000-53000/month, each year the company can earn more RMB324000-636000
Dinnerware Auto Grinding Machine
5:Advantages of automatic edge grinding machine: simple operation, replacement of a product of different specifications as long as 5-10 minutes, no need for skilled workers, as long as a porter can work 24 hours, the workers stopped, the machine does not stop, operation safety In the peak season, customers can open more machines. In the off-season, they can open fewer machines. Enterprises can reduce expenses, reduce production costs, and reduce the burden on enterprises.

Dinnerware Auto Grinding Machine
6: Automatic edging machine technical parameters:
Weight: 2.6TON
Volume: L3*W1.5*H2.2METER
Total power: 5KW
Electricity per hour: 0.3 kW
Working voltage: AC220V 50HZ
7: Edge size:
Maximum: 60CM
Minimum: 10CM
