Automatic Double Color Melamine Crockery Moulding Machine-MADE IN TAIWAN

This machine is suitable for the melamine, urea, bakelite, fiber and other thermosetting material production of tableware products. Such as bowl, cup, dish, chopsticks, spoon, plate and what kinds!

  • item no.:

  • lead time:

  • product orgin:

  • brand:

  • shipping port:

  • payment:

    TT OR LC
  • price:

  • color:

  • MOQ:

inquiry now
1Adopts 4 guide-pin with well-grind heat-treatment and the latest Japnese Yuken double proportional valve control system,be able to variable adjustment of speed and pressure,this machine designs for diversification products and well-required action and high accuracy of machine,wear-resistance and durable
2:Able to own-set according to the depth of products,fast-low speed of pressing material,infinite set of moving mold speed and action,different molds with different adjustment,stable running,high accuracy,to keep molds safe
3:Automatic operation after running action setting,with 2types of single color and double color products production.
4:Suitable for producing:double color melamine products,toilet seat cover,Bakelite switches,mahjong and the s-products with 3-dimensions which could not open vertically but horizontally

Dinnerware Compression Machine

Melamine Tableware Making Machine
2color melamine compression machine
Melamine Tableware Compression MachineMelamine Dinnerware Compression MachineMelamine Crokcery Compression Machine
Spec SHD-150T SHD-200T SHD-300T SHD-400T
Clamping Force-Ton 150 250 300 400
Plate Size-mm 660*620 680*620/720*720 720*720/900*860 900*860
Cylinder Diameter-mm 300/315 368 450 500
Stroke-mm 480 580 560 560
Daylight-mm 680 780 810 950
Pump Pressuer-kg/cm3 210 210 210 210
Motor-hp 7.5 10 15 15
Heater Capacity-kw 15 20 21.6 40
Oil Reservoir Capacity-gallon 100 120 200 250
Machine Size-L*W*H(MM) 2720*1890*2600 2300*1350*3000 2650*1850*2670 2650*1780*2870
Net Weight Approx-kgS 5000 5300/7650 8970/10500 11000
